Fluid Components International GF03 - Manual (Page 56)

FLUID COMPONENTS INTERNATIONAL LLC http://www.fluidcomponents.com
Model GF03 Flow Meter 5 2 Doc. No. 06EN003352 Rev. B
Area Cross-sectional area of pipe or duct
Diameter Inner diameter of pipe
Temp. Unit Unit of temperature
Tcal Add A value that is added to measured temperature (default is 0)
Tcal Mult A value that is multiplied by the measured
temperature (default is 1)
Relay 1 Current status of Relay 1, energized or de-energized
Above, Below, See Chapter 3 Relays, for the explanation
Inside or Outside
H : Hysteresis value (in flow rate units such as 50 SCFM etc.)
D : Delay in seconds
Relay 2 Current status of Relay 2, energized or de-energized
Port 1 Channel 1 output signal
Mode Current (4 - 20 mA) or Volts (0 - 5, 0 - 10, etc.) output
F.S. Full Scale: 100% of flow rate
Z e r o 0.00 for zero based and Min flow for non-zero based
Port 2 Channel 2 output signal
Corr1
through
Corr4
Correction Factors: Default is Corr 2 = 1 and Corr1, 3, 4 = 0
(Flow) = Corr1 + Corr2(Flow) + Corr3(Flow)2 + Corr4(Flow)3
Menu 5.8
dR gain Digital representation of A/D# for
∆
R value - derived
during front-end set-up:
∆
R = dR Gain X A/D# + dR Off
R gain Digital representation of A/D# for REF RTD value - derived
during front-end setup: REF R = R Gain X A/D# + R Off
dR Off Offset value of equation:
∆
R = dR Gain X A/D# + dR Off
Ref off Offset/constant value for REF RTD derived
during front-end set-up: REF R = R Gain X A/D/# + R Off
Offset 1 Offset for equation: REF R = R Gain X A/D# + R Off
Slope 1 Slope for equation: D/A# = current X Slope 1 + Off 1.
Corresponding to current or voltage output
