CH PSWD? — Change Password (Value)

0…9999

The password comes from the factory set to 0000. When set to 0000 the password function is disabled. By changing the

password from 0000 to some other value (any value between 0001…9999), configuration parameters will not be accessible

without first entering the password value when prompted. If the value is left at 0000, no security is invoked and unauthorized

changes can be made. Access to resetting of the totalizer is also protected by this password. If the password is lost or

forgotten, contact the manufacturer for a universal password to unlock the meter.

SER MENU – SERVICE MENU

The SER MENU menu allows access to meter set up values that may need revision due to application specific conditions and

information valuable in troubleshooting.
SSPD mps — Liquid Sound Speed (Meters per Second) (Reported by Firmware)

SSPD fps — Liquid Sound Speed (Feet per Second) (Reported by Firmware)
The flow meter performs an actual speed of sound calculation for the liquid it is measuring. This speed of sound calculation

will vary with temperature, pressure and fluid composition.
The meter will compensate for fluid sound speeds that vary within a window of ± 10% of the liquid specified in the BSC MENU.

If this range is exceeded, error code 0011 will appear on the display and the sound speed entry must be corrected.
The value indicated in SSPD measurement should be within 10% of the value entered/indicated in the BSC MENU item

FLUID SS. (The SSPD value itself cannot be edited.) If the actual measured value is significantly different (> ± 10%) than the

BSC MENU’s FLUID SS value, it typically indicates a problem with the instrument setup. An entry such as FL TYPE, PIPE OD or PIPE

WT may be in error, the pipe may not be round or the transducer spacing is not correct.

Table 10

lists sound speed values for water at varying temperatures. If the meter is measuring sound speed within 2% of the

table values, then the installation and setup of the instrument is correct.

Temperature

Velocity

Temperature

Velocity

Temperature

Velocity

° C

° F

mps

fps

° C

° F

mps

fps

° C

° F

mps

fps

0

32

1402 4600

80

176

1554 5098

160

320

1440 4724

10

50

1447 4747

90

194

1550 5085

170

338

1412 4633

20

68

1482 4862

100

212

1543 5062

180

356

1390 4560

30

86

1509 4951

110

230

1532 5026

190

374

1360 4462

40

104

1529 5016

120

248

1519 4984

200

392

1333 4373

50

122

1543 5062

130

266

1503 4931

220

428

1268 4160

60

140

1551 5089

140

284

1485 4872

240

464

1192 3911

70

158

1555 5102

150

302

1466 4810

260

500

1110 3642

Table 10: Sound Speeds for water

SIG STR — Signal Strength (Reported by Firmware)
The SIG STR value is a relative indication of the amount of ultrasound making it from the transmitting transducer to

the receiving transducer. The signal strength is a blending of esoteric transit time measurements distilled into a usable

overall reference.
The measurement of signal strength assists service personnel in troubleshooting the flow meter system. In general, expect

the signal strength readings to be greater than five on a full pipe with the transducers properly mounted. Signal strength

readings that are less than five indicate a need to choose an alternative mounting method for the transducers or that an

improper pipe size has been entered.
Signal strength below the low signal cutoff SIG C-OF value will generate a 0010 error (Low Signal Strength) and require either

a change in the SIG C-OF value or transducer mounting changes.
