Dynasonics TFX Ultra Transit Time Flow Meters User Manual

Page 44

background image

Specific Heat Capacity BTU/lb °F

Temperature

Ethylene Glycol Solution (% by Volume)

° F

° C

25

30

40

50

60

65

100

–40

–40

n/a

n/a

n/a

n/a

0.68

0.70

n/a

0

–17.8

n/a

n/a

0.83

0.78

0.72

0.70

0.54

40

4.4

0.91

0.89

0.845

0.80

0.75

0.72

0.56

80

26.7

0.92

0.90

0.86

0.82

0.77

0.74

0.59

120

84.9

0.93

0.92

0.88

0.83

0.79

0.77

0.61

160

71.1

0.94

0.93

0.89

0.85

0.81

0.79

0.64

200

93.3

0.95

0.94

0.91

0.87

0.83

0.81

0.66

240

115.6

n/a

n/a

n/a

n/a

n/a

0.83

0.69

Table 7: Specific heat capacity values for ethylene glycol/water

Transducer Spacing

XDC SPAC — Transducer Spacing Calculation (Value)

ENGLSH (Inches)

METRIC (Millimeters)

OTE:

N

This value is calculated by the firmware after all pipe parameters have been entered. The spacing value only pertains

to DTTN, DTTL, and DTTH transducer sets.

This value represents the one-dimensional linear measurement between the transducers (the upstream/downstream

measurement that runs parallel to the pipe). This value is in inches if ENGLSH was selected as UNITS; in millimeters if METRIC

was selected. This measurement is taken between the lines which are scribed into the side of the transducer blocks.
If the transducers are being mounted using the transducer track assembly, a measuring scale is etched into the track. Place

one transducer at 0 and the other at the appropriate measurement.
Rate Units

RATE UNT — Engineering Units for Flow Rate (Choice)

Gallons

Gallons

Pounds

LB

Liters

Liters

Kilograms

KG

Millions of Gallons

MGal

British Thermal Units

BTU

Cubic Feet

Cubic Ft

Thousands of BTUs

MBTU

Cubic Meters

Cubic Me

Millions of BTUs

MMBTU

Acre Feet

Acre Ft

Tons

TON

Oil Barrels

Oil Barr [42 Gallons]

Kilojoule

kJ

Liquid Barrels

Liq Barr [31.5 Gallons]

Kilowatt

kW

Feet

Feet

Megawatt

MW

Meters

Meters

Select a desired engineering unit for flow rate measurements.
Rate Interval

RATE INT — Time Interval for Flow Rate (Choice)

SEC

Seconds

MIN

Minutes

HOUR Hours

DAY

Days

Select a desired engineering unit for flow rate measurements.

BSC MENU – BASIC MENU

Page 44

March 2014
