Dynasonics TFX Ultra Transit Time Flow Meters - Manual (Page 12)

Temperature –40…185° F (–40…85° C).
Configuration Via optional keypad or PC running ULTRALINK software
(Note: not all configuration parameters are available from the keypad—for example flow and temperature calibration and advanced filter settings)
Engineering
Units
Flow Meter: Feet, gallons, cubic feet, million gallons, barrels (liquid and oil), acre-feet,
pounds, meters, cubic meters, liters, million liters, kilograms.
Energy Meter: Btu, mBtu, mmBtu, tons, kJ, kW, MW, and the flow meter list from above.
Inputs/
Outputs
RS-485: Modbus RTU or BACnet MSTP 9.6k baud standard, other baud rates, 14.4k,
19.2k, 38.4k, 56k, 57.6k and 76.8k for both Modbus and BACnet.
10/100 Base-T: RJ45, communication via Modbus TCP/IP, EtherNet/IP, or BACnet/IP.
USB 2.0: For connection of a PC running ULTRALINK configuration utility.
4-20 mA: Twelve bit, internal power, can span negative to positive flow/energy rates.
Energy Meter Model Only: Auxiliary Total Pulse Option: Opto isolated open collector transistor. 16 Hz
maximum, pulse width of 30 mSec (fixed).
Flow Meter Model Only: 0…1000 Hz: open-collector, twelve bit, can span negative to positive rates;
square-wave or turbine meter simulation outputs.
Two Alarm Outputs: Open-collector, configure as rate alarm, signal strength
alarm or totalizer pulse. When configured as a totalizing pulse the pulse width
is 100 mSec with a 1 Hz maximum frequency.
Transducers
Construction
DTTN/DTTC/DTTL: NEMA 6* (IP-67), CPVC or Valox, Ultem, Nylon cord grip,
PVC cable jacket; –40…250° F (–40…121° C)
DTTN/DTTL: NEMA 6P* (IP-68) option, CPVC, Ultem, Nylon cord grip
Polyethylene cable jacket; –40…250° F (–40…121° C)
DTTH: NEMA 6* (IP-67), PTFE, Vespel, Nickel-plated brass cord grip
PFA cable jacket; –40…350° F (–40…176° C)
DTTS: NEMA 6* (IP-67), PVC, Ultem, Nylon cord grip,
PVC cable jacket; –40…185° F (–40…85° C)
*NEMA 6 units: to a depth of 3 ft (1 m) for 30 days max. NEMA 6P units: to a depth of 100 ft (30 m) seawater equivalent density indefinitely.
Frequency
DTTS/DTTC: 2 MHz
DTTN/DTTH: 1 MHz
DTTL: 500 kHz
Cables RG59 Coaxial, 75 ohm or Twinaxial, 78 ohm (optional armored conduit).
Cable Length 990 ft (300 meter) max. in. 10 ft (3 m) increments; Submersible Conduit limited to 100 ft (30 m).
RTDs
(Energy Meters Only)
Platinum 385, 1000 ohm, 3-wire; PVC jacket cable.
Installation
DTTN (-N option) /DTTS/DTTH/DTTC: General and Hazardous Location
(see Installation Compliance above).
DTTN Transducer and IS Barrier (-F option): Class I Div. 1, Groups C&D T5 Intrinsically Safe Ex ia; CSA C22.2
No. 142 & 157; UL 913 & 916.
Software Utilities
ULTRALINK
Used to configure, calibrate and troubleshoot flow and energy meters. Connection via USB A/B cable;
software is compatible with Windows 2000, Windows XP, Windows Vista and Windows 7.
SPECIFICATIONS
Page 12 March 2014
