Energy Meter Options

RTD — Calibration Values (Value)

RTD1 A Calibration Value for RTD1 A
RTD1 B Calibration Value for RTD1 B
RTD2 A Calibration Value for RTD2 A
RTD2 B Calibration Value for RTD2 B

Inputs from two 1000 Ohm platinum RTD temperature sensors allow measurements of heating or cooling usage.
The values used to calibrate the RTD temperature sensors are derived in the laboratory and are specific to the RTD and to the

electronic circuit it is connected to. The RTDs on new units come with the calibration values already entered into the energy

meter and should not need to be changed.
Field replacement of RTDs is possible thru the use of the keypad or the software utility. If the RTDs were ordered from the

manufacturer, they will come with calibration values that need to be loaded into the energy meter.
New, non-calibrated RTDs will need to be field calibrated using an ice bath and boiling water to derive calibration values. This

procedure is outlined in the

APPENDIX

of this manual.

Surface Mount Rtds

D010-3000-301

set of two, 200° C maximum temperature (20 feet of cable)

Insertion Rtds

D010-3000-200

single, 3 inch (75 mm), 0.25 inch OD

D010-3000-203

single, 6 inch (150 mm), 0.25 inch OD

Table 9: RTDs

FLOW ONLY METER OPTIONS

Two independent open collector transistor outputs are included with the flow only model. Each output can be configured

independently for one of the following:
CONTROL/HZ — Control Options (Choice)
Select either Control 1 or Control 2 to program.
TOTALIZE — Totalizer Output Options

TOT MULT —Totalizer Multiplier (Value)
Sets the multiplier value applied to the totalizing pulse output.

FLOW — Flow Alarm Output Options

FLOW — Flow Alarm Values

ON (Value)

Sets value at which the alarm output will turn ON.

OFF (Value)

Sets value at which the alarm output will turn OFF.

SIG STR — Signal Strength Alarm Options

SIG STR — Signal Strength Alarm Values

ON (Value)

Sets value at which the alarm output will turn ON.

OFF (Value)

Sets value at which the alarm output will turn OFF.

ERRORS
Alarm outputs on any error condition. See

Error Codes

at the end of this manual.

BSC MENU – BASIC MENU

Page 48

March 2014
