Totalizer Units

TOTL UNT — Totalizer Units

Gallons

Gallons

Pounds

LB

Liters

Liters

Kilograms

KG

Millions of Gallons

MGal

British Thermal Units

BTU

Cubic Feet

Cubic Ft

Thousands of BTUs

MBTU

Cubic Meters

Cubic Me

Millions of BTUs

MMBTU

Acre Feet

Acre Ft

Tons

TON

Oil Barrels

Oil Barr [42 Gallons]

Kilojoule

kJ

Liquid Barrels

Liq Barr [31.5 Gallons]

Kilowatt

kW

Feet

Feet

Megawatt

MW

Meters

Meters

Select a desired engineering unit for flow accumulator (totalizer) measurements.
Totalizer Exponent

TOTL E — Flow Totalizer Exponent Value (Choice)

E(–1)E6

Utilized for setting the flow totalizer exponent. This feature is useful for

accommodating a very large accumulated flow or to increase totalizer resolution

when flows are small (displaying fractions of whole barrels, gallons, etc.) The

exponent is a × 10

n

multiplier, where “n” can be from –1 (Ч 0.1)…6 (Ч 1000,000).

Table 8

should be referenced for valid entries and their influence on the display.

Selection of E-1 and E0 adjusts the decimal point on the display. Selection of E1, E2

and E3 causes an icon of Ч 10, Ч 100 or × 1000 respectively to appear to the right of

the total flow display value.

Table 8: Exponent values

Minimum Flow Rate

MIN RATE — Minimum Flow Rate Settings (Value)

A minimum rate setting is entered to establish filter software settings and the lowest rate value that will be displayed.

Volumetric entries will be in the rate units and interval selected previousley. For unidirectional measurements, set MIN RATE to

zero. For bidirectional measurements, set MIN RATE to the highest negative (reverse) flow rate expected in the piping system.

OTE:

N

The flow meter will not display a flow rate at flows less than the MIN RATE value. As a result, if the MIN RATE is set to a

value greater than zero, the flow meter will display the MIN RATE value, even if the actual flow/energy rate is less than

the MIN RATE.

For example, if the MIN RATE is set to 25 and actual rate is 0, the meter display will indicate 25. Another example, if the

MIN RATE is set to -100 and the actual flow is -200, the meter will indicate -100. This can be a problem if the meter

MIN RATE is set to a value greater than zero because at flows below the MIN RATE the rate display will show zero flow,

but the totalizer which is not affected by the MIN RATE setting will keep totalizing.

Maximum Flow Rate

MAX RATE — Maximum Flow Rate Settings (Value)

A maximum volumetric flow rate setting is entered to establish filter software settings. Volumetric entries will be in the rate

units and Interval selected previousley. For unidirectional measurements, set MAX RATE to the highest (positive) flow rate

expected in the piping system. For bidirectional measurements, set MAX RATE to the highest (positive) flow rate expected in

the piping system.

Exponent

Display Multiplier

E–1

Ч 0.1 (ч10)

E0

× 1 (no multiplier)

E1

× 10

E2

× 100

E3

× 1000

E4

× 10,000

E5

× 100,000

E6

× 1000,000

BSC MENU – BASIC MENU
