DESCRIPTION
The INR? query reads and clears the contents of
the INternal state change Register(INR). The
INR register (table below) records the
completion of various internal operations and
state transitions.
Note : This command only supports 0 bit and 13
bit.
Internal State Register Structure (INR)
Bit
Bit
Value
Description
15…14
0
Reserved for future use
13
8192
1
Trigger is ready
12
4096
1
Pass/Fail test detected desired outcome
11
2048
1
Waveform processing has terminated in Trace D
10
1024
1
Waveform processing has terminated in Trace C
9
512
1
Waveform processing has terminated in Trace B
8
256
1
Waveform processing has terminated in Trace A
7
128
1
A memory card, floppy or hard disk exchange has been detected
6
64
1
Memory card, floppy or hard disk has become full in “AutoStore
Fill” mode
5
32
0
Reserved for LeCroy use
4
16
1
A segment of a sequence waveform has been acquired
3
8
1
A time-out has occurred in a data block transfer
2
4
1
A return to the local state is detected
1
2
1
A screen dump has terminated
0
1
1
A new signal has been acquired
QUERY SYNTAX
INR?
RESPONSE FORMAT
INR
EXAMPLE
If we send INR? query after have triggered
the INR register:
Command message1:
INR?
STATUS
INR?
Query
