127
DESCRIPTION The WAVEFORM_SETUP command specifies
the amount of data in a waveform to be
transmitted to the controller. The command
controls the settings of the parameters listed
below.
Note: This command currently only support NP
Notation
FP first point NP number of points
SP sparsing
Sparsing (SP): The sparsing parameter defines
the interval between data points. For example:
SP = 0 sends all data points
SP = 1 sends all data points
SP = 4 sends every 4th data point
Number of points (NP): The number of points
parameter indicates how many points should be
transmitted. For example:
NP = 0 sends all data points
NP = 1 sends 1 data point
NP = 50 sends a maximum of 50 data points
NP = 1001 sends a maximum of 1001 data
points
First point (FP): The first point parameter
specifies the address of the first data point to be
sent. For waveforms acquired in sequence mode,
this refers to the relative address in the given
segment. For example:
FP = 0 corresponds to the first data point
FP = 1 corresponds to the second data point
FP = 5000 corresponds to data point 5001
The WAVEFORM_SETUP? query returns the
transfer parameters currently in use.
COMMAND SYNTAX
WaveForm_SetUp SP, , NP,
, FP,
WAVEFORM TRANSFER WAVEFORM_SETUP, WFSU
Command /Query
