windows-based Program control
The DSP Configurator Control Program is compatible with Windows XP, Windows Vista,
and Windows 7, and provides remote control of the input gain/attenuation, output volume
output adjustment, and other features.
DSP Configurator can control the DMP 128 by any of the three control ports, RS-232,
USB, or LAN.
Updates to this program can be downloaded from the Extron website at
.
installing the DsP configurator Program
The program is contained on the Extron Software Products disk.
Install the software as follows:
1.
Insert the disk into the drive.
2.
Click the Software tab or software icon. The software page opens.
notE: If the DVD setup program does not start automatically, run
Launch.exe
from the DVD ROM directory using Windows My Computer.
Figure 9.
DvD Software menu
DMP 128 • Software Control
13
