Dante installation
and operation
(at Models only)
DMP 128 at Bus
DMP 128 devices equipped with an AT bus use Dante technology to provide high
performance digital audio networking over standard TCP/IP networks. Dante allows audio
channels to be transported across a switched Ethernet data network while meeting the
quality requirements of professional audio.
Audio signals are converted by the DMP 128 AT models, processed, then routed to the
AT bus for availablity over the network. The audio network can be shared with control
traffic or unrelated data traffic. Audio channels can be unicast or multicast to make the
best use of available bandwidth.
The DMP 128 AT models are both a transmitter (source), and receiver (destination) for
signals on a Dante network. Transmitters and receivers can be located anywhere on the
Ethernet network and can be relocated without reconfiguring the DMP 128 AT or the
network.
This section describes the DMP 128 AT network installation, configuration, and control
using Dante Controller for Windows and includes:
• DmP 128 AT Bus
• Dante Controller Software Installation
• Creating a Physical Dante Network
• Dante Controller Configuration
• Selecting Inputs and Outputs for Dante
• Signal Routing with Dante
• Using the Extron Expansion Bus with DmP 128 AT Devices
DMP 128 • Dante Installation and Operation 112
