DMP software
This section describes the control software for the DMP 128, including:
• Software Control
• Windows-based Program Control
• DSP Configurator Program Basics
• Audio level, mix-point, Processing Blocks, and Signal Chains
• mic/Line Input Signal Chain Controls
• Telephone Rx (DmP 128 C P and DmP 128 C P AT only)
• Line Output Channels
• virtual Bus Returns
• Output mix matrix
• virtual Send Bus mix matrix
• Expansion Outputs mix matrix
• Group masters
• Digital I/O Ports
• Emulate mode and Live mode
• Presets
• Protected Configuration
• DSP Configurator Windows menus
• Optimizing Audio Levels
• Signal Path Building Blocks
software control
The DMP 128 can be controlled using the DSP Configurator software, using SIS
commands with hyper terminal or DataViewer (see
SIS Programming and Control
on page 129), and accessed using embedded WebPages (see HTmL Operation on
page 155).
The DmP 128 has the following connection options:
• RS-232 — One single stack 3-pole, 3.5 mm captive screw connector is used for
bi-directional RS-232 (± 5 V) serial control.
See
Rear Panel Features and Cabling on page 6, for additional details on
connecting the RS-232 port.
• LAN — 10 Mbps, 100 Mbps, half duplex, full duplex connections are supported. Two
LEDs indicate connection and activity status. The device has the following default
Ethernet configurations:
IP Address: 192.168.254.254 Default Gateway: 0.0.0.0
Subnet mask: 255.255.0.0 DHCP: OFF
See Rear Panel Features and Cabling on page 6, and Connection Options
on page 129 for additional details on connecting the LAN.
• USB 2.0 — A Mini B-type USB connector located on the front panel provides
high-speed USB 2.0 connectivity to a host computer, backward compatible to 1.0.
DMP 128 • Software Control 12
