htML operation
This section describes HTML operation and control of the DMP 128, including:
•
•
•
•
•
The DMP 128 can be accessed by a PC or controller from a LAN or WAN using the
Ethernet port and a web browser such as the Microsoft
®
Internet Explorer. The browser
display of device status or operation has the appearance of web pages. This chapter
describes the factory-installed HTML pages, which are always available and cannot be
erased or overwritten.
notE: If the Ethernet connection to the device is unstable, try turning off the proxy
server in the Web browser. In Microsoft Internet Explorer, click
Tools > Internet Options > Connections > LAN Settings, uncheck the
"Use a proxy server..." box, and then click OK.
Download the startup Page
Access the device using HTmL pages as follows:
1.
Start the Web browser program.
2.
Click in the browser Address field.
3.
Enter the device IP address directly into the address field.
notE: If the local system administrators have not changed the value, the
factory-specified default IP address is 192.168.254.254.
4.
If a custom display page is available, enter a slash (
/) and the file name to open.
notE: The browser address field should display the address in the following
format:
xxx.xxx.xxx.xxx/{optional_file_name.HTML}
. The following
characters are invalid in file names:
{space}
+ ~ , @ = ‘ [ ] { } < > ’ " ; : > \
?
