table 3: Mic/Line inputs to output Mix-points ( a )
a
Mic/Line inputs to outputs X6) a
Mic/Line inputs to outputs X6)
Mic/Line Input 1 to Output 1 20000 Mic/Line Input 2 to Output 1 20100
Mic/Line Input 1 to Output 2 20001 Mic/Line Input 2 to Output 2 20101
Mic/Line Input 1 to Output 3 20002 Mic/Line Input 2 to Output 3 20102
Mic/Line Input 1 to Output 4 20003 Mic/Line Input 2 to Output 4 20103
Mic/Line Input 1 to Output 5 20004 Mic/Line Input 2 to Output 5 20104
Mic/Line Input 1 to Output 6 20005 Mic/Line Input 2 to Output 6 20105
Mic/Line Input 1 to Output 7 20006 Mic/Line Input 2 to Output 7 20106
Mic/Line Input 1 to Output 8 20007 Mic/Line Input 2 to Output 8 20107
Mic/Line Input 3 to Output 1 20200 Mic/Line Input 4 to Output 1 20300
Mic/Line Input 3 to Output 2 20201 Mic/Line Input 4 to Output 2 20301
Mic/Line Input 3 to Output 3 20202 Mic/Line Input 4 to Output 3 20302
Mic/Line Input 3 to Output 4 20203 Mic/Line Input 4 to Output 4 20303
Mic/Line Input 3 to Output 5 20204 Mic/Line Input 4 to Output 5 20304
Mic/Line Input 3 to Output 6 20205 Mic/Line Input 4 to Output 6 20305
Mic/Line Input 3 to Output 7 20206 Mic/Line Input 4 to Output 7 20306
Mic/Line Input 3 to Output 8 20207 Mic/Line Input 4 to Output 8 20307
Mic/Line Input 5 to Output 1 20400 Mic/Line Input 6 to Output 1 20500
Mic/Line Input 5 to Output 2 20401 Mic/Line Input 6 to Output 2 20501
Mic/Line Input 5 to Output 3 20402 Mic/Line Input 6 to Output 3 20502
Mic/Line Input 5 to Output 4 20403 Mic/Line Input 6 to Output 4 20503
Mic/Line Input 5 to Output 5 20404 Mic/Line Input 6 to Output 5 20504
Mic/Line Input 5 to Output 6 20405 Mic/Line Input 6 to Output 6 20505
Mic/Line Input 5 to Output 7 20406 Mic/Line Input 6 to Output 7 20506
Mic/Line Input 5 to Output 8 20407 Mic/Line Input 6 to Output 8 20507
Mic/Line Input 7 to Output 1 20600 Mic/Line Input 8 to Output 1 20700
Mic/Line Input 7 to Output 2 20601 Mic/Line Input 8 to Output 2 20701
Mic/Line Input 7 to Output 3 20602 Mic/Line Input 8 to Output 3 20702
Mic/Line Input 7 to Output 4 20603 Mic/Line Input 8 to Output 4 20703
Mic/Line Input 7 to Output 5 20604 Mic/Line Input 8 to Output 5 20704
Mic/Line Input 7 to Output 6 20605 Mic/Line Input 8 to Output 6 20705
Mic/Line Input 7 to Output 7 20606 Mic/Line Input 8 to Output 7 20706
Mic/Line Input 7 to Output 8 20607 Mic/Line Input 8 to Output 8 20707
Mic/Line Input 9 to Output 1 20800 Mic/Line Input 10 to Output 1 20900
Mic/Line Input 9 to Output 2 20801 Mic/Line Input 10 to Output 2 20901
Mic/Line Input 9 to Output 3 20802 Mic/Line Input 10 to Output 3 20902
Mic/Line Input 9 to Output 4 20803 Mic/Line Input 10 to Output 4 20903
Mic/Line Input 9 to Output 5 20804 Mic/Line Input 10 to Output 5 20904
Mic/Line Input 9 to Output 6 20805 Mic/Line Input 10 to Output 6 20905
Mic/Line Input 9 to Output 7 20806 Mic/Line Input 10 to Output 7 20906
Mic/Line Input 9 to Output 8 20807 Mic/Line Input 10 to Output 8 20907
DMP 128 • Reference Information 176
