3. To move away from the highlighted block or set of sequential blocks, or to highlight
non-sequential blocks:
a. After highlighting blocks in step 2, press and hold , then use the navigation
( , , , and ) keys to move to the next desired element. As long as
is held down, the block moved away from is not highlighted. If the block is
highlighted, it will be unhightlighted.
b. Release , but do not press any navigation keys.
4. To highlight another element or group of elements, repeat steps 2 and 3 as required.
5. To cut or copy, press or .
6. To save a preset, press , then right arrow , then down arrow , then
press (see figure 62).
7. The Save a Preset dialog box appears.
a. to the preset number field and type a specific preset number.
b. to the preset name field and type a preset name.
notE: Unless entering a specific number and name, DSP Configurator
enters the next sequential unused preset number.
c. to highlight OK and press .
Alt T Enter
Figure 62. Saving a Preset Using Keyboard Navigation
DMP 128 • Software Control 99
