table 1: Level control
a
input gain control X6) Level b
Pre-mixer gain X6) Level
Mic/Line Input 1 40000 X6! Mic/Line Input 1 40100 X6!
Mic/Line Input 2 40001 X6! Mic/Line Input 2 40101 X6!
Mic/Line Input 3 40002 X6! Mic/Line Input 3 40102 X6!
Mic/Line Input 4 40003 X6! Mic/Line Input 4 40103 X6!
Mic/Line Input 5 40004 X6! Mic/Line Input 5 40104 X6!
Mic/Line Input 6 40005 X6! Mic/Line Input 6 40105 X6!
Mic/Line Input 7 40006 X6! Mic/Line Input 7 40106 X6!
Mic/Line Input 8 40007 X6! Mic/Line Input 8 40107 X6!
Mic/Line Input 9 40008 X6! Mic/Line Input 9 40108 X6!
Mic/Line Input 10 40009 X6! Mic/Line Input 10 40109 X6!
Mic/Line Input 11 40010 X6! Mic/Line Input 11 40110 X6!
Mic/Line Input 12 40011 X6! Mic/Line Input 12 40111 X6!
Telephone Rx 40012 X6! Telephone Rx 40112 X6!
d
Post-mixer trim X6) Level e
Volume out control X6) Level
Output 1 60100 X6! Output 1 60000 X6!
Output 2 60101 X6! Output 2 60001 X6!
Output 3 60102 X6! Output 3 60002 X6!
Output 4 60103 X6! Output 4 60003 X6!
Output 5 60104 X6! Output 5 60004 X6!
Output 6 60105 X6! Output 6 60005 X6!
Output 7 60106 X6! Output 7 60006 X6!
Output 8/Telephone Tx 60107 X6! Output 8 60007 X6!
Telephone Tx 60008 X6!
c
Virtual return gain X6) Level
Virtual Return A 50000 X6!
Virtual Return B 50001 X6!
Virtual Return C 50002 X6!
Virtual Return D 50003 X6!
Virtual Return E 50004 X6!
Virtual Return F 50005 X6!
Virtual Return G 50006 X6!
Virtual Return H 50007 X6!
notE:
• For expanded coverage of setting audio levels, including comprehensive tables
of mix-point address, see
DSP SIS Commands for mix-point Level and mute
Control on page 170.
• Telephone Tx and Rx commands available on DMP 128 P models only.
