command
ascii command
(host to device)
response
(device to host)
additional description
Telephone commands
notE: Prior to using the the modem, ensure the country code is set using DSP Configurator (see
page 126). To receive proper responses, place the DMP 128 in verbose mode 3.
Initialize phone
E
AT+FCLASS=8,PHON
}
PhonOK
]
Must be sent prior to dialing or
going off hook
Dial number string
E
ATDT
X@
,PHON
}
PhonOK
]
Send DTMF string
X@
to modem
Off hook
E
AT+VLS=13,PHON
}
PhonOffHook
]
Connects line
On hook
E
AT+VLS=0, PHON
}
PhonOnHook
]
Disconnects line
Flash
E
ATD&,PHON
}
PhonOK
]
Flashes line
Phone state
E
AT+VLS?,PHON
}
PhonSts
X! ]
X!
00 = On hook
13 = Off hook
Dial single digit
E
AT.
X#
,PHON
}
PhonOK
]
Send single DTMF pulse
X#
to
modem
Receive gain 0 dB
E
AT:UB5
%2C1000%0D
,1PHON
}
PhonOK
]
Sets receive gain to 0 dB
Receive gain -12 dB
E
AT:UB5
%2C400%0D
,1PHON
}
PhonOK
]
Sets receive gain to -12 dB
Receive mute
E
AT:UB5
%2C0%0D
,1PHON
}
PhonOK
]
Mutes the phone receiver
Telephone responses (unsolicited)
notE: The following unsolicited responses alert the DMP 128 control system of an incoming call, line status changes, or an incoming
Caller ID. To receive proper responses, place the DMP 128 in verbose mode 3.
PhonDial_Tone
]
Line is off hook, dial tone present
PhonRinging_Tone
]
Far end ringing
PhonBusy_Tone
]
Far end busy
PhonLine_Intr
]
Far end has terminated the call
PhonError_Non_Voice
]
Phone was not initialized properly
PhonError
]
Unrecognized phone command
PhonRING
]
Incoming call
PhonDATE=
X% ]
From Caller ID of incoming call,
X%
= Current Date
PhonTIME=
X^ ]
From Caller ID of incoming call,
X^
= Current time
PhonNAME=
X& ]
From Caller ID of incoming call,
X&
= Name
PhonNMBR=
X@ ]
From Caller ID of incoming call,
X@
= Phone Number
notEs:
X!
= Hook status
00=on hook, 13
=
off hook
X@
= Numeric string
Numeric string. Valid characters are: 0 through 9,*,#, no spaces
X#
= Single character
Valid characters are: 0 through 9,*,#
X%
= Date
Date in mmdd format
X^
= Current time
Caller ID current time in hhss format
X&
= Character String
Up to 10 characters
