point-to-point LAN segment), or can be connected to two or more
bridges (i.e. it is served by a shared medium LAN segment). This
function allows the P2P status of the link to be manipulated
administratively. True is P2P enabling. False is P2P disabling.
 Admin Edge: The port directly connected to end stations won ‘t create
bridging loop in the network. To configure the port as an edge port, set
the port to
―True‖ status.
 Admin Non Stp: The port includes the STP mathematic calculation.
True is not including STP mathematic calculation. False is including
the STP mathematic calculation.
 Click
Apply .
