802.1Q Configuration
 Pull down the selection item and focus on 802.1Q then press
Apply
button to set the VLAN Operation Mode in 802.1Q mode.
 Enable GVRP Protocol: Tick the checkbox to enable GVRP protocol.
This checkbox is available while the VLAN Operation Mode is in
802.1Q mode.
 Select the port you want to configure.
 Link Type: There are 3 types of link type.
 Access Link: Single switch only, it allows the user to group ports
by assigning the same Untagged VID. While this link type is set,
the Untagged VID column field is available but the Tagged VID
column field is disabled.
 Trunk Link: The extended application of Access Link. It allows
the user to group ports by assigning the same Tagged VID across
2 or more switches. Having set this link type, the Tagged VID
column field is available but the Untagged VID column field is
disabled.
 Hybrid Link: Both Access Link and Trunk Link are available.
 Untagged VID: Assign the untagged frame VID.
 Tagged VID: Assign the tagged frame VID.
 Click
Apply button to have the settings taken effect.
 You can see the link type, untagged VID, and tagged VID information of
each port in the table below on the screen.
