mode
Vlanmode
[portbase| 802.1q |
gvrp]
V To set switch VLAN
mode.
switch(vlan)#vlanmode portbase
or
switch(vlan)#vlanmode 802.1q
or
switch(vlan)#vlanmode gvrp
no vlan V No VLAN Switch(vlan)#no vlan
Ported based VLAN configuration
vlan port-based
grpname
[Group Name]
grpid
[GroupID]
port
[PortNumbers]
V Add new port based
VALN
switch(vlan)#vlan port-based
grpname test grpid 2 port 2-4
or
switch(vlan)#vlan port-based
grpname test grpid 2 port 2,3,4
show vlan [GroupID]
or
show vlan
V Show VLAN
information
switch(vlan)#show vlan 23
no vlan group
[GroupID]
V Delete port base group
ID
switch(vlan)#no vlan group 2
IEEE 802.1Q VLAN
vlan 8021q name
[GroupName]
vid
[VID]
V Change the name of
VLAN group, if the
group didn
‘t exist, this
command can
‘t be
applied.
switch(vlan)#vlan 8021q name
test vid 22
vlan 8021q port
[PortNumber]
access-link untag
[UntaggedVID]
V Assign a access link
for VLAN by port, if the
port belong to a trunk
group, this command
can
‘t be applied.
switch(vlan)#vlan 8021q port 3
access-link untag 33
vlan 8021q port
[PortNumber]
trunk-link tag
[TaggedVID List]
V Assign a trunk link for
VLAN by port, if the
port belong to a trunk
switch(vlan)#vlan 8021q port 3
trunk-link tag 2,3,6,99
or
