Port Statistics
The following information provides the current port statistic information.
 Port: Displays the port number.
 Type: Displays the media type of the port.
 Link: The status of linking —‗Up‘ or ‗Down‘.
 State: The user can set the state of the port as ‗Enable‘ or ‗Disable‘ via
Port Control. When the state is disabled, the port will not transmit or
receive any packet.
 Tx Good Packet: The counts of transmitting good packets via this port.
 Tx Bad Packet: The counts of transmitting bad packets (including
undersize [less than 64 bytes], oversize, CRC Align errors, fragments
and jabbers packets) via this port.
 Rx Good Packet: The counts of receiving good packets via this port.
 Rx Bad Packet: The counts of receiving good packets (including
undersize [less than 64 bytes], oversize, CRC error, fragments and
jabbers) via this port.
 Tx Abort Packet: The aborted packet while transmitting.
 Packet Collision: The counts of collision packet.
 Packet Dropped: The counts of dropped packet.
 Rx Bcast Packet: The counts of broadcast packet.
 Rx Mcast Packet: The counts of multicast packet.
 Click
Clear button to clean all counts.
