Trap Managers interface
SNMPV3 Configuration
Configure the SNMP V3 function.
Context Table
Configure SNMP v3 context table. Assign the context name of context table.
Click Add to add context name. Click Remove to remove the
unwanted context name.
User Profile
Configure SNMP v3 user table..
 User ID: Set up the user name.
 Authentication Password: Set up the authentication password.
 Privacy Password: Set up the private password.
 Click
Add to add the context name.
 Click
Remove to remove the unwanted context name.
