System Information
Assign the system name and location and view the system information
 System Name: Assign the system name of the switch (The maximum
length is 64 bytes)
 System Description: Describes the switch.
 System Location: Assign the switch physical location (The maximum
length is 64 bytes).
 System Contact: Enter the name of contact person or organization.
 Firmware Version: Displays the swi tch‘s firmware version
 Kernel Version: Displays the kernel software version
 MAC Address: Displays the unique hardware address assigned by
manufacturer (default)
 And than, click
Apply button.
IP Configuration
User can configure the IP Settings and DHCP client function in here.
 DHCP Client: Enable or disable the DHCP client function. When DHCP
client function is enabled, the industrial switch will be assigned an IP
address from the network DHCP server. The default IP address will be
replaced by the assigned IP address on DHCP server. After user click
Apply button, a popup dialog shows up. It is to inform the user that
when the DHCP client is enabled, the current IP will lose and user
should find the new IP on the DHCP server.
 IP Address: Assign the IP address that the network is using. If DHCP
client function is enabled, and then the user doesn
‘t need to assign the
IP address. And, the network DHCP server will assign the IP address
displaying in this column for the industrial switch. The default IP is
192.168.16.1.
 Subnet Mask: Assign the subnet mask to the IP address. If DHCP
client function is enabled, and then the user does not need to assign
the subnet mask.
