 Security Name (User ID): Assign the user name that you have set up
in user table.
 Group Name: Set up the group name.
 Click
Add to add the context name.
 Click
Remove to remove the unwanted context name.
Access Table
Configure SNMP v3 access table.
 Context Prefix: Set up the context name.
 Group Name: Set up the group.
 Security Level: Set up the access level.
 Context Match Rule: Select the context match rule.
 Read View Name: Set up the read view.
 Write View Name: Set up the write view.
 Notify View Name: Set up the notify view.
 Click
Add to add the context name.
 Click
Remove to remove the unwanted context name.
MIBview Table
Configure MIB view table.
 ViewName: Set up the name.
 Sub-Oid Tree: Fill the Sub OID.
 Type: Select the type —excluded or included.
 Click
Add to add the context name.
 Click
Remove to remove the unwanted context name.
