DS1875
PON Triplexer and SFP Controller
84
______________________________________________________________________________________
Table 02h, Register D8h to F7h: EMPTY
Table 02h, Register F8h to F9h: MAN BIAS
FACTORY
DEFAULT
00h
READ
ACCESS PW2
WRITE ACCESS
PW2 and BIAS EN = 1
MEMORY
TYPE Volatile
FAh
RESERVED RESERVED RESERVED RESERVED RESERVED RESERVED RESERVED MAN_CLK
BIT
7
BIT
0
When BIAS EN (Table 02h, Register 80h) is written to 0, bit 0 of this byte controls the updates of the MAN BIAS
value to the BIAS output. The values of MAN BIAS should be written with a separate write command. Setting bit 0
to a 1 clocks the MAN BIAS value to the output DAC.
1.
Write the MAN BIAS value with a write command.
2.
Set the MAN_CLK bit to a 1 with a separate write command.
3.
Clear the MAN_CLK bit to a 0 with a separate write command.
Table 02h, Register FAh: MAN_CNTL
FACTORY
DEFAULT
00h
READ
ACCESS PW2
WRITE ACCESS
PW2 and BIAS EN = 1
MEMORY
TYPE Volatile
F8h RESERVED RESERVED
2
12
2
11
2
10
2
9
2
8
2
7
F9h 2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
BIT
7
BIT
0
When BIAS EN (Table 02h, Register 80h) is written to 0, writes to these bytes control the BIAS DAC.
