DS1875

PON Triplexer and SFP Controller

66

______________________________________________________________________________________

Table 02h, Register 89h: CONFIG

FACTORY

DEFAULT

00h

READ

ACCESS

PW2

WRITE

ACCESS

PW2

MEMORY TYPE

Nonvolatile (SEE)

89h

FETG DIR

TX-F LEN

M3QT LEN

ASEL

BOLFS

RSSI_FC

RSSI_FF

EN5TO8B

BIT 7

BIT 0

Configure the memory location and the polarity of the digital outputs.

BIT

7

FETG DIR: Chooses the direction or polarity of the FETG output for normal operation.
0 = (Default) Under normal operation, FETG is pulled low.
1 = Under normal operation, FETG is pulled high.

BIT

6

TX-F LEN: The TX-F output pin always reflects the wired-OR of all TX-F enabled alarm states. This
bit enables the latching of the alarm state for the TX-F output pin.
0 = (Default) Not latched.
1 = The alarm bits are latched until cleared by a TX-D transition or power-down. If the V

CC

alarm is

enabled for either FETG or TX-F, then latching is disabled until after the first V

CC

measurement is

made above the V

CC

ALARM LO set point to allow for proper operation during slow power-on

cycles.

BIT

5

M3QT LEN: This bit enables the latching of the alarm for the M3QT.
0 = (Default) Not latched.
1 = The alarm bit is latched until cleared by setting the M3QT RESET bit (Byte 78h).

BIT

4

ASEL: Address select.
0 = (Default) Device address of A2h.
1 = Device address is equal to the value found in the DEVICE ADDRESS byte (Table 02h, 8Ch).

BIT

3

BOLFS: Bias open-loop full scale.
0 = (Default) Full scale is 600μA.
1 = Full scale is 1.2mA.

BITS

2:1

RSSI_FC and RSSI_FF: RSSI force coarse and RSSI force fine. Control bits for RSSI mode of
operation on the MON3 conversion.
00b = (Default) Normal RSSI mode of operation.
01b = The fine settings of scale and offset are used for MON3 conversions.
10b = The coarse settings of scale and offset are used for MON3 conversions.
11b = Normal RSSI mode of operation.

BIT

0

EN5TO8B: This bit enables MON5–MON8 conversion (voltage of D0–D3 pins).
0 = (Default) Temperature, V

CC

, and MON1–MON8 conversions are enabled.

1 = Temperature, V

CC

, and MON1–MON4 conversions are enabled.
