DS1875
Table 02h, Register 8Ah: RESERVED
FACTORY DEFAULT 00h
READ ACCESS PW2
WRITE ACCESS PW2
MEMORY TYPE Nonvolatile (SEE)
This register is reserved.
Table 02h, Register 8Bh: MOD RANGING
FACTORY DEFAULT 00h
READ ACCESS PW2
WRITE ACCESS PW2
MEMORY TYPE Nonvolatile (SEE)
8Bh RESERVED RESERVED RESERVED RESERVED RESERVED MOD
2
MOD
1
MOD
0
BIT 7 BIT 0
The lower nibble of this byte controls the full-scale range of the Modulation DAC
BITS 7:3 RESERVED (Default = 0)
BITS 2:0
MOD[2:0]: MOD FS RANGING: 3-bit value to select the FS output voltage for MOD. Default is 000b
and creates a FS of 1.25V.
MOD[2:0] % OF 1.25V FS VOLTAGE (V)
000b 100.00 1.250
001b 80.05 1.001
010b 66.75 0.834
011b 50.13 0.627
100b 40.15 0.502
101b 33.50 0.419
110b 28.74 0.359
111b 25.17 0.315
