DS1875
TABLE 01h (PW1)
WORD 0 WORD 1 WORD 2 WORD 3 ROW
(HEX)
ROW
NAME BYTE 0/8 BYTE 1/9 BYTE 2/A BYTE 3/B BYTE 4/C BYTE 5/D BYTE 6/E BYTE 7/F
80 <7> PW1 EE EE EE EE EE EE EE EE EE
88 <7> PW1 EE EE EE EE EE EE EE EE EE
90 <7> PW1 EE EE EE EE EE EE EE EE EE
98 <7> PW1 EE EE EE EE EE EE EE EE EE
A0 <7> PW1 EE EE EE EE EE EE EE EE EE
A8 <7> PW1 EE EE EE EE EE EE EE EE EE
B0 <7> PW1 EE EE EE EE EE EE EE EE EE
B8 <7> PW1 EE EE EE EE EE EE EE EE EE
C0 <7> PW1 EE EE EE EE EE EE EE EE EE
C8 <7> PW1 EE EE EE EE EE EE EE EE EE
D0 <7> PW1 EE EE EE EE EE EE EE EE EE
D8 <7> PW1 EE EE EE EE EE EE EE EE EE
E0 <7> PW1 EE EE EE EE EE EE EE EE EE
E8 <7> PW1 EE EE EE EE EE EE EE EE EE
F0 <7> PW1 EE EE EE EE EE EE EE EE EE
F8
<11> ALARM
TRAP
ALARM 3 ALARM 2 ALARM 1 ALARM 0 WARN 3 WARN 2 RESERVED RESERVED
Table 01h Register Map
ACCESS
CODE
<0> <1> <2> <3> <4> <5> <6> <7> <8> <9> <10> <11>
Read
Access
All All All PW2 All N/A PW1 PW2 N/A PW2 All
Write
Access
See each
bit/byte
separately
PW2 N/A
All and
DS1875
hardware
PW2 +
mode
bit
All All PW1 PW2 PW2 N/A PW1
PON Triplexer and SFP Controller
