DS1875
Table 02h, Register BEh: HBIAS
FACTORY DEFAULT 00h
READ ACCESS PW2
WRITE ACCESS PW2
MEMORY TYPE Nonvolatile (SEE)
BEh 2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
BIT 7 BIT 0
Fast-comparison DAC setting for high BIAS. Comparisons greater than V HBIAS , found on the MON1 pin, create a
BIAS HI alarm.
V HBIAS
=
Full Scale
255
HBIAS
Table 02h, Register BFh: MAX BIAS
FACTORY DEFAULT 00h
READ ACCESS PW2
WRITE ACCESS PW2
MEMORY TYPE Nonvolatile (SEE)
BFh 2 12 2 11 2 10 2 9 2 8 2 7 2 6 2 5
BIT 7 BIT 0
This value defines the maximum DAC value allowed for the upper 8 bits of BIAS output during all operations.
PON Triplexer and SFP Controller
