DS1875
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on MON1–MON8,
BEN, BMD, and TX-D Pins
Relative to Ground .................................-0.5V to (V
CC
+ 0.5V)*
Voltage Range on V
CC
, SDA, SCL,
D0–D3, and TX-F Pins Relative to Ground...............-0.5V to 6V
Operating Temperature Range ...........................-40°C to +95°C
Programming Temperature Range .........................0°C to +85°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature...........................Refer to the IPC/JEDEC
J-STD-020 Specification.
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Main Supply Voltage V CC (Note 1) +2.85 +3.9 V
High-Level Input Voltage
(SDA, SCL, BEN)
V IH:1
0.7 x
V CC
V CC +
0.3
V
Low-Level Input Voltage
(SDA, SCL, BEN)
V IL:1 -0.3
0.3 x
V CC
V
High-Level Input Voltage
(TX-D, LOSI, D0, D1, D2, D3)
V IH:2 2.0
V CC +
0.3
V
Low-Level Input Voltage
(TX-D, LOSI, D0, D1, D2, D3)
V IL:2 -0.3 +0.8 V
AC ELECTRICAL CHARACTERISTICS
(V CC = +2.85V to +3.9V, T A = -40°C to +95°C, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Supply Current I CC (Notes 1, 2) 5.5 10 mA
Output Leakage
(SDA, TX-F, D0, D1, D2, D3)
I LO (Note 2) 1 μA
I OL = 4mA 0.4 Low-Level Output Voltage
(SDA, TX-F, FETG, D0, D1, D2, D3)
V OL
I
OL
= 6mA 0.6
V
High-Level Output Voltage
(FETG)
V OH I OH = 4mA
V CC -
0.4
V
FETG Before Recall (Note 3) 10 100 nA
Input Leakage Current
(SCL, BEN, TX-D, LOSI)
I LI:1 1 μA
Digital Power-On Reset POD 1.0 2.2 V
Analog Power-On Reset POA 2.1 2.75 V
* Subject to not exceeding +6V.
RECOMMENDED OPERATING CONDITIONS
(T A = -40°C to +95°C, unless otherwise noted.)
ABSOLUTE MAXIMUM RATINGS
PON Triplexer and SFP Controller
