DS1875
PON Triplexer and SFP Controller
76 ______________________________________________________________________________________
Table 02h, Register BAh: TX-F ENABLE 1
FACTORY DEFAULT 00h
READ ACCESS PW2
WRITE ACCESS PW2
MEMORY TYPE Nonvolatile (SEE)
BAh TEMP EN VCC EN MON1 EN MON2 EN MON3 EN MON4 EN RESERVED RESERVED
BIT 7 BIT 0
Configures the maskable interrupt for the TX-F pin.
BIT 7
TEMP EN: Enables/disables active interrupts on the TX-F pin due to temperature measurements outside
the threshold limits.
0 = Disable (Default)
1 = Enable
BIT 6
VCC EN: Enables/disables active interrupts on the TX-F pin due to V CC measurements outside
the threshold limits.
0 = Disable (Default)
1 = Enable
BIT 5
MON1 EN: Enables/disables active interrupts on the TX-F pin due to MON1 measurements outside the
threshold limits.
0 = Disable (Default)
1 = Enable
BIT 4
MON2 EN: Enables/disables active interrupts on the TX-F pin due to MON2 measurements outside the
threshold limits.
0 = Disable (Default)
1 = Enable
BIT 3
MON3 EN: Enables/disables active interrupts on the TX-F pin due to MON3 measurements outside the
threshold limits.
0 = Disable (Default)
1 = Enable
BIT 2
MON4 EN: Enables/disables active interrupts on the TX-F pin due to MON4 measurements outside the
threshold limits.
0 = Disable (Default)
1 = Enable
BITS 2:0 RESERVED (Default = 0)
