DS1875
Table 02h, Register 92h to 93h: V
CC
SCALE
Table 02h, Register 94h to 95h: MON1 SCALE
Table 02h, Register 96h to 97h: MON2 SCALE
Table 02h, Register 98h to 99h: MON3 FINE SCALE
Table 02h, Register 9Ah to 9Bh: MON4 SCALE
Table 02h, Register 9Ch to 9Dh: MON3 COARSE SCALE
FACTORY
CALIBRATED
READ
ACCESS PW2
WRITE
ACCESS PW2
MEMORY TYPE
Nonvolatile (SEE)
92h, 94h,
96h, 98h,
9Ah, 9Ch
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
93h, 95h,
97h, 99h,
9Bh, 9Dh
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
BIT
7
BIT
0
Controls the scaling or gain of the FS voltage measurements. The factory-calibrated value produces an FS
voltage of 6.5536V for V
CC
and 2.5V for MON1, MON2, MON3, and MON4.
Table 02h, Register 9Eh to A1h: RESERVED
FACTORY
DEFAULT
00h
READ
ACCESS PW2
WRITE
ACCESS PW2
MEMORY
TYPE Nonvolatile
(SEE)
These registers are reserved.
PON Triplexer and SFP Controller
______________________________________________________________________________________
71
