DS1875
Lower Memory, Register 08h to 09h: V
CC
ALARM HI
Lower Memory, Register 0Ch to 0Dh: V
CC
WARN HI
Lower Memory, Register 10h to 11h: MON1 ALARM HI
Lower Memory, Register 14h to 15h: MON1 WARN HI
Lower Memory, Register 18h to 19h: MON2 ALARM HI
Lower Memory, Register 1Ch to 1Dh: MON2 WARN HI
Lower Memory, Register 20h to 21h: MON3 ALARM HI
Lower Memory, Register 24h to 25h: MON3 WARN HI
Lower Memory, Register 28h to 29h: MON4 ALARM HI
Lower Memory, Register 2Ch to 2Dh: MON4 WARN HI
FACTORY DEFAULT
FFFFh
READ
ACCESS All
WRITE
ACCESS
PW2
MEMORY TYPE
Nonvolatile (SEE)
08h, 0Ch,
10h, 14h, 18h,
1Ch, 20h,
24h, 28h, 2Ch
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
09h, 0Dh,
11h, 15h, 19h,
1Dh, 21h,
25h, 29h, 2Dh
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
BIT
7
BIT
0
Voltage measurement updates above this unsigned threshold set its corresponding alarm or warning bit.
Voltage measurements equal to or below this threshold clear its alarm or warning bit.
PON Triplexer and SFP Controller
