DS1875
PON Triplexer and SFP Controller
46 ______________________________________________________________________________________
POWER-ON VALUE 0000h
READ ACCESS All
WRITE ACCESS N/A
MEMORY TYPE Volatile
62h, 64h,
66h, 68h,
6Ah
2 15 2 14 2 13 2 12 2 11 2 10 2 9 2 8
63h, 65h,
67h, 69h,
6Bh
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
BIT 7 BIT 0
Left-justified unsigned voltage measurement.
POWER-ON VALUE 00h
READ ACCESS All
WRITE ACCESS N/A
MEMORY TYPE
6Ch, 6Dh 0 0 0 0 0 0 0 0
BIT 7 BIT 0
These registers are reserved. The value when read is 00h.
Lower Memory, Register 62h to 63h: V CC VALUE
Lower Memory, Register 64h to 65h: MON1 VALUE
Lower Memory, Register 66h to 67h: MON2 VALUE
Lower Memory, Register 68h to 69h: MON3 VALUE
Lower Memory, Register 6Ah to 6Bh: MON4 VALUE
Lower Memory, Register 6Ch to 6D: RESERVED
