DS1875
Table 02h, Register C8h to C9h: MON5 SCALE
Table 02h, Register CAh to CBh: MON6 SCALE
Table 02h, Register CCh to CDh: MON7 SCALE
Table 02h, Register CEh to CFh: MON8 SCALE
FACTORY
CALIBRATED
READ
ACCESS PW2
WRITE
ACCESS PW2
MEMORY TYPE
Nonvolatile (SEE)
C8h, CAh,
CCh, CEh
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
C9h, CBh,
CDh, CFh
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
BIT
7
BIT
0
Controls the scaling or gain of the FS voltage measurements. The factory-calibrated value produces an FS
voltage of 2.5V for MON5, MON6, MON7, and MON8.
Table 02h, Register D0h to D1h: MON5 OFFSET
Table 02h, Register D2h to D3h: MON6 OFFSET
Table 02h, Register D4h to D5h: MON7 OFFSET
Table 02h, Register D6h to D7h: MON8 OFFSET
FACTORY
DEFAULT
00h
READ
ACCESS PW2
WRITE
ACCESS
PW2
MEMORY TYPE
Nonvolatile (SEE)
D0h, D2h,
D4h, D6h
S S 2
15
2
14
2
13
2
12
2
11
2
10
D1h, D3h,
D5h, D7h
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
BIT
7
BIT
0
Allows for offset control of these voltage measurements if desired.
