DS1875
Table 00h Register Descriptions
Table 00h, Register 80h to 81h: MON5 VALUE
Table 00h, Register 82h to 83h: MON6 VALUE
Table 00h, Register 84h to 85h: MON7 VALUE
Table 00h, Register 86h to 87h: MON8 VALUE
POWER-ON VALUE 0000h
READ ACCESS All
WRITE ACCESS N/A
MEMORY TYPE Volatile
80h, 82h,
84h, 86h
2 15 2 14 2 13 2 12 2 11 2 10 2 9 2 8
81h, 83h,
85h, 87h
2 7 2 6 2 5 2 4 2 3 2 2 2 1 2 0
BIT 7 BIT 0
Left-justified unsigned voltage measurement.
Table 01h Register Descriptions
Table 01h, Register 80h to F7h: PW1 EEPROM
POWER-ON VALUE 00h
READ ACCESS PW1
WRITE ACCESS PW1
MEMORY TYPE Nonvolatile (EE)
80h to F7h EE EE EE EE EE EE EE EE
BIT 7 BIT 0
EEPROM for PW1-level access.
PON Triplexer and SFP Controller
