DS2151Q
022697 5/46
PIN DESCRIPTION TYPE SYMBOL
20 BTS I Bus Type Select. Strap high to select Motorola bus timing; strap low to
select Intel bus timing. This pin controls the function of the RD(DS),
ALE(AS), and WR(R/W) pins. If BTS=1, then these pins assume the function
listed in parenthesis ().
21
22 RTIP
RRING
– Receive Tip and Ring. Analog inputs for clock recovery circuitry; connects
to a 1:1 transformer (see Section 12 for details).
23 RVDD – Receive Analog Positive Supply. 5.0 volts. Should be tied to DVDD and
TVDD pins.
24 RVSS – Receive Signal Ground. 0.0 volts. Should be tied to local ground plane
25
26 XTAL1
XTAL2 – Crystal Connections. A pullable 6.176 MHz crystal must be applied to
these pins. See Section 12 for crystal specifications.
27 INT1 O Receive Alarm Interrupt 1. Flags host controller during alarm conditions
defined in Status Register 1. Active low, open drain output.
28 INT2 O Receive Alarm Interrupt 2. Flags host controller during conditions defined
in Status Register 2. Active low, open drain output.
29 TTIP – Transmit Tip. Analog line driver output; connects to a step–up transformer
(see Section 12 for details).
30 TVSS – Transmit Signal Ground. 0.0 volts. Should be tied to local ground plane.
31 TVDD – Transmit Analog Positive Supply. 5.0 volts. Should be tied to DVDD and
RVDD pins.
32 TRING – Transmit Ring. Analog line driver outputs; connects to a step–up trans-
former (see Section 12 for details).
33 TCHBLK O Transmit Channel Block. A user programmable output that can be forced
high or low during any of the 24 T1 channels. Useful for blocking clocks to
a serial UART or LAPD controller in applications where not all T1 channels
are used such as Fractional T1, 384K bps service, 768K bps, or ISDN–PRI.
Also useful for locating individual channels in drop–and–insert applications.
See Section 13 for timing details.
34 TLCLK O Transmit Link Clock. 4 KHz or 2 KHz (ZBTSI) demand clock for the TLINK
input. See Section 13 for timing details.
35 TLINK I Transmit Link Data. If enabled via TCR1.2, this pin will be sampled during
the F–bit time on the falling edge of TCLK for data insertion into either the FDL
stream (ESF) or the Fs bit position (D4) or the Z–bit position (ZBTSI). See
Section 13 for timing details.
36 TSYNC I/O Transmit Sync. A pulse at this pin will establish either frame or multiframe
boundaries for the DS2151Q. Via TCR2.2, the DS2151Q can be pro-
grammed to output either a frame or multiframe pulse at this pin. If this pin
is set to output pulses at frame boundaries, it can also be set via TCR2.4 to
output double–wide pulses at signaling frames. See Section 13 for timing
details.
37 DVDD – Digital Positive Supply. 5.0 volts. Should be tied to RVDD and TVDD pins.
38 TCLK I Transmit Clock. 1.544 MHz primary clock.
39 TSER I Transmit Serial Data. Transmit NRZ serial data, sampled on the falling edge
of TCLK.
