DS2151Q

022697 39/46

ABSOLUTE MAXIMUM RATINGS*

Voltage on Any Pin Relative to Ground

–1.0V to +7.0V

Operating Temperature

0

°

C to +70

°

C

(–40

°

C to +85

°

C for DS2151QN)

Storage Temperature

–55

°

C to +125

°

C

Soldering Temperature

260

°

C for 10 seconds

* This is a stress rating only and functional operation of the device at these or any other conditions above those

indicated in the operation sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods of time may affect reliability.

RECOMMENDED DC OPERATION CONDITIONS

(0

°

C to 70

°

C)

(–40

°

C to +85

°

C for DS2151QN)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNITS

NOTES

Logic 1

V

IH

2.0

V

DD

+0.3

V

Logic 0

V

IL

–0.3

+0.8

V

Supply

V

DD

4.75

5.25

V

1

CAPACITANCE

(t

A

=25

°

C)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNITS

NOTES

Input Capacitance

C

IN

5

pF

Output Capacitance

C

OUT

7

pF

DC CHARACTERISTICS

(0

°

C to 70

°

C; V

DD

=5V + 5%)

(–40

°

C to +85

°

C for DS2151QN)

PARAMETER

SYMBOL

MIN

TYP

MAX

UNITS

NOTES

Supply Current @ 5V

I

DD

65

mA

2

Input Leakage

I

IL

–1.0

+1.0

µ

A

3

Output Leakage

I

LO

1.0

µ

A

4

Output Current (2.4V)

I

OH

–1.0

mA

Output Current (0.4V)

I

OL

+4.0

mA

NOTES:

1. Applies to RVDD, TVDD, and DVDD.

2. TCLK=1.544 MHz.

3. 0.0V < V

IN

< V

DD

.

4. Applies to INT1 and INT2 when 3–stated.
