made transparent by the Transmit Transparency Regis-
ters.
9.0 CLOCK BLOCKING REGISTERS
The Receive Channel Blocking Registers
(RCBR1/RCBR2/RCBR3) and the Transmit Channel
Blocking Registers (TCBR1/TCBR2/TCBR3) control
the RCHBLK and TCHBLK pins respectively. The
RCHBLK and TCHCLK pins are user programmable
outputs that can be forced either high or low during indi-
vidual channels. These outputs can be used to block
clocks to a UART or LAPD controller in Fractional T1 or
ISDN–PRI applications. When the appropriate bits are
set t o a one, the RCHBLK and TCHCLK pins will be held
high during the entire corresponding channel time. See
the timing in Section 13 for an example.
RCBR1/RCBR2/RCBR3: RECEIVE CHANNEL BLOCKING REGISTERS (Address=6C to 6E Hex)
(MSB) (LSB)
CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
SYMBOL POSITION NAME AND DESCRIPTION
CH24 RCBR3.7 Receive Channel Blocking Registers.
0=force the RCHBLK pin to remain low during this channel time
CH1 RCBR1.0 1=force the RCHBLK pin high during this channel time
TCBR1/TCBR2/TCBR3: TRANSMIT CHANNEL BLOCKING REGISTERS (Address=32 to 34 Hex)
(MSB) (LSB)
CH8 CH7 CH6 CH5 CH4 CH3 CH2 CH1
CH16 CH15 CH14 CH13 CH12 CH11 CH10 CH9
CH24 CH23 CH22 CH21 CH20 CH19 CH18 CH17
SYMBOL POSITION NAME AND DESCRIPTION
CH24 TCBR3.7 Transmit Channel Blocking Registers.
0=force the TCHBLK pin to remain low during this channel time
CH1 TCBR1.0 1=force the TCHBLK pin high during this channel time
10.0 ELASTIC STORES OPERATION
The DS2151Q has two onboard two–frame (386 bits)
elastic stores. These elastic stores have two main pur-
poses. First, they can be used to rate convert the T1
data stream to 2.048 Mbps (or a multiple of 2.048 Mbps)
which is the E1 rate. Secondly, they can be used to
absorb the differences in frequency and phase between
the T1 data stream and an asynchronous (i.e., not fre-
quency locked) backplane clock. Both elastic stores
contain full controlled slip capability which is necessary
for this second purpose. The receive side elastic store
can be enabled via CCR1.2 and the transmit side elastic
store is enabled via CCR1.7. The elastic stores can be
forced to a known depth via the Elastic Store Reset bit
(CCR3.6).
10.1 Receive Side
If the receive side elastic store is enabled (CCR1.2=1),
then the user must provide either a 1.544 MHz
(CCR1.3=0) or 2.048 MHz (CCR1.3=1) clock at the
SYSCLK pin. The user has the option of either providing
a frame sync at the RFSYNC pin (RCR2.3=1) or having
the RFSYNC pin provide a pulse on frame boundaries
(RCR2.3=0). If the user wishes to obtain pulses at the
frame boundary, then RCR2.4 must be set to zero and if
the user wishes to have pulses occur at the multiframe
RCBR1 (6C)
RCBR2 (6D)
RCBR3 (6E)
TCBR1 (32)
TCBR2 (33)
TCBR3 (34)
