K5 System Technical Guide

4. Online Monitors search

Function: Search the certain range of Monitor which is for checking the information of the online
monitor. After startup this operation, the Door Station search and display the present online mon-
itor according to the setup range automatically. Operation steps are show as below:

5. Online Devices

This tool is used to identify whether C5-MDS, C5-IPC and C5-IMC are connected. When it is star-
tup, the connection states come out by turn automatically. If one of these devices is connected, it
shows online, otherwise, it shows offline. Usually, this tool is used in project installation and main-
tenance.

Press #9008 then Installer
code to enter the Debug
mode, then 1# to enter
Tools page

Debug Tools menu is shown:

Press “4” to select

Debug Tools menu is shown:

Press “5” to select

Enter the starting number
and ending starting , and
# to start search the moni-
tors on line

The online devices status
will be checked immedi-
ately

> > D e b u g S t a t e < <

1 - # To o l s

0 - # R e d i a l

2 - # E x i t s

2 . S e t u p

4 . O n l i n e M o n i t o r s
5 . O n l i n e D e v i c e s

*Back

Tools

1 . I n s t a l l e r S e t u p

3 . C a r d M e m o r y

* Back

# Save

(Search Range)

[ - - - - ] ~ [- - - - ]

4 . O n l i n e M o n i t o r s
