Page 46 K5 System Technical Guide
• Monitor Program (Debug State->3. Monitor Program).
Access Monitor Program in Debug Mode (Also See 1.1, Access Monitor program in normal mode
• Card Management [Debug State->4. Card Management]
When in Debug Mode,
press “3#”
Enter Add Card menu, and
Room Code is asked.
[1] Add Card
Monitor Program is
launched
Input Room Code, then
press “#” Key.
Program the monitor according
to the instruction
Swipe the card to be added
V i d e o E n t r y S y s t e m
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
> > D E B U G S T A T E < <
- - - - - - - - - - - - - - - - - - - - - - - - - - -
3 - # M o n i t o r P r o g r a m
2 - # S e t u p
1 - # I n s t a l l e r S e t u p
6 - # O n l i n e D e v i c e s . . .
E X I T: # - 9 0 0 9
5 - # O n l i n e M o n i t o r. . .
- - - - - - - - - - - -To o l s - - - - - - - - - -
4 - # C a r d M a n a g e
V i d e o E n t r y S y s t e m
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
[ 3 ] M o n i t o r P r o g r a m
- - - - - - - - - - - - - - - - - - - - - - - - - - -
N e w M . c o d e [ - - - - ]
O l d M . c o d e [ - - - - ]
* B a c k
1 . P r e s s C a l l B u t t o n
o f t h e M o n i t o r
2 . I n p u t n e w C o d e
W i t h i n 1 0 S e c o n d s
3 . P r e s s # t o p r o g r a m
P r o g r a m m i n g S t e p s :
V i d e o E n t r y S y s t e m
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
[ 3 ] M o n i t o r P r o g r a m
- - - - - - - - - - - - - - - - - - - - - - - - - - -
N e w M . c o d e [ 0 0 0 2 ]
O l d M . c o d e [ 0 0 0 1 ]
* B a c k
1 . P r e s s C a l l B u t t o n
o f t h e M o n i t o r
2 . I n p u t n e w C o d e
W i t h i n 1 0 S e c o n d s
3 . P r e s s # t o p r o g r a m
P r o g r a m m i n g S t e p s :
V i d e o E n t r y S y s t e m
> > [ 7 ] [ 1 ]
A d d C a r d
- - - -
P l e a s e I n p u t M . C o d e
* B a c k # S a v e
V i d e o E n t r y S y s t e m
> > [ 7 ] [ 1 ]
A d d C a r d
0 1 0 1
S h o w t h e C a r d
* B a c k # S a v e
V i d e o E n t r y S y s t e m
> > [ 7 ] [ 1 ]
A d d C a r d
0 1 0 1
C a r d : 1 5 9 7 7 1 3 1
U p d a t e d
* B a c k # S a v e
U
s
e
r
C
a
rd
Item Descriptions Factory Set
1. Add Card Input the user code then swipe the card to be added NONE
2. Delete By Card Swipe the card to delete it NONE
3. Delete By M. Code To delete all the cards attached to the user code NONE
4. Cards information To show the amount of cards and counts NONE
5. Format To Delete all the card information saved on the door station
Chapter 4 K5 System Settings
