Page 130 K5 System Technical Guide
Item Description
1. Monitor Time Displays the monitor time elapsed
2. Device Name Displays the name of the monitored device
Item Description
1. Capture Capture a picture of the video window
2. Record Performs/Stop recording the video window
3. Unlock 1 Unlock the latch of the entrance
4. Unlock 2 Unlock the latch of the entrance
5. Speaker Volume Adjust speaker volume via up and down button
6. Mic Volume Adjust mic volume via up and down button
7. Hang up Exit the communication window
8. Maximum Maximize the video window
5.4.4.3§Name§&§Function§in§Pop-up§Call§Window
It will pop up a calling window for video and operation when there is a calling to DS/CDS or an in-
coming calling from DS/CDS.
1 2 3 4 5 6 7
8
Chapter 5 K5 System Softwares
