K5 System Technical Guide
§
§ 3.3§One§Entrance§with§Network
Network connection is required when communication between different buildings or between
buildings and Switchboard. C5-IPC is needed to effect the network connection.
3.3.1§Layout
1
2
3
6
5
4
7
8
9
#
0
*
RF CARD
C5-IPC
C5-F414
1
2
3
4
1
2
3
4
PS5
C5-F414
1
2
3
4
1
2
3
4
Floor 1
C5-IPC
C5-F414
C5-F414
Exit Button
Floor N
To LAN/WAN
RVV 2*1.0
CAT5 Cable
3.3.2§List§of§Accessories
Model
Description
DS
Outdoor station, call monitor and unlock the door
Monitor
User terminal, to communicate with door station, other monitors and Switchboard
Distributor
To separate data, audio, video signal to each monitor, and power monitor
PS5
Adjustable DC power supply
C5-IPC
Controlling center and IP Converter
