V-Tech CAT5 System Technical Guide - Manual (Page 126)

Page 126 K5 System Technical Guide
2) Press the PA key of the
related C5-IPC, A window
will pop up showing the IP
address of the C5-IPC.
§ § 5.4§IP§Agent§2012
5.4.1§Introduction
IP-Agent is the main software of PC Station. It’s a Switchboard that enables you communicate with
user, entrance of blocks, common entrances and other Switchboards in one residential area via IP
network.
• Unlock door when talking with entrances or monitoring.
• Capture picture of entrances when monitoring or calling entrances
• Record video automatically when answering incoming call
• Record video manually when monitoring or calling entrances
• Share the Dtabase built by IP-Device
5.4.2§ Login
Click on icon that has been created automatically, IP-Agent gets started. To Access IP-
Agent, you must log in with a registered account at first
1. On your desktop, double click the IP-Agent icon, the login dialog comes up.
2. Enter the user ID and password
Default ID: device
Default Password: 123456
Chapter 5 K5 System Softwares
