Page 9
3
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
X510-8
ITEM
PART IDENTIFICATION
NO.
Parts Listing
ITEM
PART IDENTIFICATION
NO.
ITEM
PART IDENTIFICATION
NO.
68
Axle Drive Gear
69
Pressure Spring
70
Spring Retaining Plate
71
Wheel Bearing Adjusting Nut
72
Lock Nut
73
Nut & Pin Assembly – Inner Lock
74
KIT – Outer Wheel Bearing
75
Wheel Hub
76
KIT – Inner Wheel Bearing
77
Oil Seal
78
Wheel Bearing Spindle
Power-Lok & Trak-Lok
Differential
79
Case – Differential
80
Gear – Differential
81
Shaft – Differential
82
Snap Ring
83
Spacer – Diff. Gear (dished)
84
Plate – Differential
85
Disc – Differential
86
Plate – Differential
87
Clip – Diff. Clutch Retainer
88
Flange Half – Differential Case
89
Cap Half – Differential Case
90
Shaft – Differential
91
Pinion – Differential
92
Gear – Differential
93
Ring – Differential Gear
94
Plate – Differential
95
Disc – Differential
96
Disc – Differential (dished)
97
Plate – Differential (dished)
98
Bolt – Differential Case
Dodge Model 44 Front Axles
1
(1)
Housing – Axle Service
2
Drive Pinion & Gear Assembly
3
Slinger – Inner Pinion Bearing
4
KIT – Inner Pinion Bearing
5
Inner Pinion Shims
6
Baffle – Pinion Bearing
7
Outer Pinion Shims
8
KIT – Outer Pinion Bearing
9
Slinger – Outer Pinion Bearing
10
Seal – Pinion Oil
11
(2)
End Yoke Assembly
12
Washer – Pinion Nut
13
Pinion Nut
14
(2)
Companion Flange Assembly
15
Carrier Cover
16
Carrier Cover Gasket / Sealant
17
Plug – Carrier Cover
18
Bolt – Carrier Cover
19
(1)
Differential Bearing Cap
20
(1)
Bolt – Differential Bearing Cap
21
KIT – Differential Bearing
22
Shim – Differential Bearing
23
Case – Differential
24
Bolt – Drive Gear
25
Pinion – Differential
26
Gear – Differential
27
Thrustwasher – Diff. Pinion
28
Thrustwasher – Diff. Gear
29
Shaft – Differential Pinion
30
Lock – Differential Shaft
31
Seal & Guide Tube
32
Nut - Hex Slotted
33
Cotter Pin
34
Adjusting Split RIng
35
Upper Socket Assembly
36
Lock Nut
37
Lower Socket Assembly
38
Snap Ring
39
Stop Screw
40
Jam Nut
41
Knuckle Assembly
42
(1)
Nut - Hex Slotted
43
(1)
Cotter Pin
44
(1)
Tie Rod Assembly
45
Shaft & Joint Assembly
46
Slinger – Spindle Yoke
(pressed on axle shaft if used)
47
Oil Seal
48
Spacer – Wheel Bearing Spindle
49
Oil Seal – Block Vee
50
Needle Bearing Assembly
51
Wheel Bearing Spindle
52
Brake Mounting Nut
53
Oil Seal
54
KIT – Inner Wheel Bearing
55
Wheel Hub
56
KIT – Outer Wheel Bearing
57
Wheel Bearing Lockwasher
58
Wheel Bearing Nut
59
Lockwasher – Wheel Brg Nut
60
Drive Flange Gasket
61
Axle Drive Flange
62
Snap Ring
63
Hub Cap
64
Nut
65
Lockwasher
66
Stud
67
Hub Cap
