191
(1) Contact Vehicle Manufacturer
(2) See Spicer Driveline Catalog J300P Section 10
Check availability on all Powr-Lok parts before ordering
X510-9
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
IHC Model 60 Rear Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Shim – Drive Pinion
5 Baffle – Pinion Bearing
6 Shim – Pinion Bearing
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
10 (2) End Yoke Assembly
11 Washer – Pinion Nut
12 Pinion Nut
13 (2) Companion Flange Assembly
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
18 (1) Differential Bearing Cap
19 (1) Bolt – Differential Bearing Cap
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Differential Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
30 (1) Brake Mounting Bolt
31 (1) Brake Mounting Nut
32 (1) Hub Seal
33 (1) KIT – Inner Wheel Bearing
34 (1) KIT – Outer Wheel Bearing
35 (1) Wheel Hub
36 Spindle Nut
37 Lockwasher – Spindle Nut
38 Shaft – Axle Flanged Drive
39 Seal – Inboard Shaft
40 Retainer Ring – Wheel Bearing
41 Wheel Bearing Assembly
42 Seal – Outboard Shaft
43 Retainer – Oil Seal
Power-Lok & Trak-Lok
Differential
44 Case – Differential
45 Gear – Differential
46 Spacer – Diff. Gear (dished)
47 Plate – Differential
48 Disc – Differential
49 Plate – Diff. (selective thick.)
50 Clip – Differential Clutch Retainer
51 Flange Half - Differential Case
52 Cap Half – Differential Case
53 Shaft – Differential
54 Pinion – Differential
55 Gear – Differential
56 Ring – Differential
57 Plate – Differential
58 Disc – Differential
59 Disc – Differential (dished)
60 Plate – Differential (dished)
61 Bolt – Differential Case
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for use on flat flange type
cover. Paper or cork gasket recommended for use on ribbed flange cover.
Common Axle Kits - Use with All Applications
ITEM DESCRIPTION KIT PART
NO. NUMBER
ITEM DESCRIPTION KIT PART
NO. NUMBER
Carrier Cover 602918, 902998, 603053 706128X
603259, 603494, 602755
706160X
603054, 603492, 603490
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
Inner Pinion Bearing 706046X
3 KIT – Inner Pinion Bearing
Outer Pinion Bearing 706045X
7 KIT – Outer Pinion Bearing
Outer Pinion Bearing 706047X
20 KIT – Differential Bearing
Pinion & Bearing Adjusting Shim 706672X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
Differential Bearing Adjusting Shim 706673X
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
Differential & Pinion Shim 706674X
4 Shim – Drive Pinion Adjusting
6 Shim – Pinion Bearing Adjusting
11 Washer – Pinion Nut
12 Pinion Nut
15 Carrier Cover Gasket / Sealant
21 Shim – Differential Bearing
