Spicer Front and Rear Axle Catalog - Manual (Page 249)

243
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
X510-9
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
AMC/Jeep Model 60 Rear Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 KIT – Inner Pinion Bearing
4 Shim – Drive Pinion
5 Baffle – Pinion Bearing
6 Shim – Pinion Bearing
7 KIT – Outer Pinion Bearing
8 Slinger – Outer Pinion Bearing
9 Seal – Pinion Oil
10 (2) End Yoke Assembly
11 Washer – Pinion Nut
12 Pinion Nut
13 (2) Companion Flange Assembly
14 Carrier Cover
15 Carrier Cover Gasket / Sealant
16 Plug – Carrier Cover
17 Bolt – Carrier Cover
18 (1) Differential Bearing Cap
19 (1) Bolt – Differential Bearing Cap
20 KIT – Differential Bearing
21 Shim – Differential Bearing
22 Case – Differential
23 Bolt – Drive Gear
24 Pinion – Differential
25 Gear – Differential
26 Thrustwasher – Diff. Pinion
27 Thrustwasher – Differential Gear
28 Shaft – Differential Pinion
29 Lock – Differential Shaft
30 Brake Mounting Bolt
31 Brake Mounting Nut
32 Hub Seal
33 KIT – Inner Wheel Bearing
34 KIT – Outer Wheel Bearing
35 (1) Wheel Hub
36 Spindle Nut
37 Lockwasher – Spindle Nut
38 Shaft – Axle Flanged Drive
39 Seal – Inboard Shaft
40 Retainer Ring – Wheel Bearing
41 Wheel Bearing Assembly
42 Seal – Outboard Shaft
43 Retainer – Oil Seal
Power-Lok & Trak-Lok
Differential
44 Case – Differential
45 Gear – Differential
46 Spacer – Diff. Gear (dished)
47 Plate – Differential
48 Disc – Differential
49 Plate – Diff. (selective thick.)
50 Clip – Differential Clutch Retainer
51 Flange Half - Differential Case
52 Cap Half – Differential Case
53 Shaft – Differential
54 Pinion – Differential
55 Gear – Differential
56 Ring – Differential
57 Plate – Differential
58 Disc – Differential
59 Disc – Differential (dished)
60 Plate – Differential (dished)
61 Bolt – Differential Case
