Spicer Front and Rear Axle Catalog - Manual (Page 71)

X510-9
65
Miscellaneous Small Parts
(3) Contact Vehicle Manufacturer
Bills of Material Description & Item Number (Refer to
"Exploded View" at the front of this section) 603471 603472 603479 603480 603482
Inner Pinion Bearing Kit 4 706031X 706031X 706031X 706031X 706031X
Pinion & Bearing Adjusting Shim 706358X 706358X 706358X 706358X 706358X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim 706376X 706376X 706376X 706376X 706376X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing 8 706030X 706030X 706030X 706030X 706030X
Carrier Cover (inc. 15, 16, 17, 18) 706112X 700038 706154X 706154X 700038
Differential Bearing Adj. Shim (16, 22) 706086X 706086X 706086X 706086X 706086X
Differential Bearing 21 706032X 706032X 706032X 706032X 706032X
Seal & Guide Tube 31 — 36352 — — 36352
Seal 32542-1 — 32542-1 32542-1 —
Guide 30703 — 30703 30703 —
Steering Knuckle Assembly - RH 706105X 706113X 706156X 706151X 706113X
(inc. items 32, 33, 34, 36, 41)
Steering Knuckle Assembly - LH N.I. 706106X 706114X 706157X 706152X 706114X
Socket Assy (32,33,34,35,36,37,38) 706116X 706116X 30354 35183 706116X
Steering Arm N.I. — — 706155X 706153X —
Wheel Spindle Seal & Bearing 706527X 706527X — — 706527X
(inc. items 47, 48, 49, 50)
Wheel Bearing Spindle 706539X 706539X 22137X 25789X 706539X
(inc. items 47, 48, 49, 50, 51 or 74)
Stop Screw 39 31026-1 31026-1 31026-1 30902 31026-1
Jam Nut 40 500381-3 500381-3 500381-3 500381-3 500381-3
Oil Seal 47 38128 38128 — — 38128
Spacer - Wheel Bearing Spindle 48 38106 38106 — — 38106
Oil Seal - Block Vee 49 36361 36361 — — 36361
Needle Bearing Assembly 50 550759 550759 30339 30339 550759
Nut - Brake Mounting 52 30688 30688 30688 30688 30688
Oil Seal 53 — — — 35311 —
Inner Wheel Bearing 54/76 706110X 706110X 706110X 706139X 706110X
Cup — — — — —
Cone — — — — —
Wheel Hub 55 — — — — (3) —
Outer Wheel Bearing 56/74 706111X 706111X 706111X 706111X 706111X
Gasket-Drive Flange 60 — — — 30344 —
Flange-Axle Drive 61 — — — 30340 —
Snap RIng 62 31624 31624 31624 31624 31624
External Hub Cap 63 31552 31552 31552 32001 31552
Nut 64 — — — 500371-3 —
Lockwasher 65 — — — 501209-3 —
Stud 66 — — — 31017 —
Internal Hub Cap 67 31552 31552 31552 32001 31552
Axle Drive Gear 68 31125 31125 31125 — 31125
Pressure Spring 69 35218 35218 35218 — 35218
Plate-Spring Retaining 70 32589 32589 32589 — 32589
Wheel Bearing Adjusting Nut 71 31139 31139 31139 31139 31139
Retaining Lock Nut 72 36569 36569 36569 36569 36569
Nut & Pin Assembly-Inner Lock 73 21588X 21588X 21588X 21588X 21588X
Wheel Hub 75 — (3) — (3) — (3) — — (3)
Oil Seal 77 35313 35313 35313 — 35313
Hub Lock Assembly N.I. 26133-3X 26133-3X — 27369-3X —
Knuckle Oil Seal & Bolt N.I. — — 706207X 706230X —
King Pin Bearing N.I. — — 706159X 706150X —
Ford Model 44 Front Axles
