Spicer Front and Rear Axle Catalog - Manual (Page 141)

139
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
X510-9
ITEM PART IDENTIFICATION
NO.
Parts Listing
ITEM PART IDENTIFICATION
NO.
ITEM PART IDENTIFICATION
NO.
GMC / Chevrolet Model 60 Front Axles
1 (1) Housing – Axle Service
2 Drive Pinion & Gear Assembly
3 Slinger – Inner Pinion Bearing
4 KIT – Inner Pinion Bearing
5 Inner Pinion Shim
6 Baffle – Pinion Bearing
7 Outer Pinion Shims
8 KIT – Outer Pinion Bearing
9 Slinger – Outer Pinion Bearing
10 Seal – Pinion Oil
11 (2) End Yoke Assembly
12 Washer – Pinion Nut
13 Pinion Nut
14 (2) Companion Flange Assembly
15 Carrier Cover
16 Carrier Cover Gasket / Sealant
17 Plug – Carrier Cover
18 Bolt – Carrier Cover
19 (1) Differential Bearing Cap
20 (1) Bolt – Differential Bearing Cap
21 KIT – Differential Bearing
22 Shim – Differential Bearing
23 Case – Differential
24 Bolt – Drive Gear
25 Pinion – Differential
26 Gear – Differential
27 Thrustwasher – Diff. Pinion
28 Thrustwasher – Diff. Gear
29 Shaft – Differential Pinion
30 Lock – Differential Shaft
31 Seal & Guide Tube
32 Seal – Upper King Pin
33 Grease Retainer
34 Oil Seal
35 KIT – Lower King Pin Bearing
36 Stop Screw
37 Jam Nut
38 (1) Tie Rod Assembly
39 Cotter Pin
40 Lube Fitting
41 Nut – Hex Tapered
42 Lockwasher – Upper King Pin Cap
43 Steering Arm (LH only)
Upper King Pin Cap (RH only)
44 Gasket – King Pin Cap
45 Compression Spring
46 Retainer Spring
47 King Pin Bushing
48 King Pin
49 Knuckle Assembly
50 Lower King Pin Bearing Cap
51 Lockwasher – Lower King Pin Cap
52 Hex Bolt – Lower King Pin Cap
53 Shaft & Joint Assembly
54 Slinger – Spindle Yoke
(pressed on axle shaft if used)
55 Oil Seal
56 Spacer – Wheel Bearing Spindle
57 Oil Seal - Block Vee
58 Needle Bearing Assembly
59 Wheel Bearing Spindle
60 Brake Mounting Nut
61 Oil Seal
62 KIT – Inner Wheel Bearing
63 KIT – Outer Wheel Bearing
64 (1) Wheel Hub
65 Inner Wheel Bearing Nut
66 Lock Nut
67 Outer Wheel Bearing Nut
68 Spring Retaining Plate
69 Pressure Spring
70 Axle Drive Gear
71 Snap Ring
72 Hub Cap
Drive Pinion & Gear Assembly
2 Drive Pinion & Gear Assembly
3 Slinger – Inner Pinion Bearing
4 KIT – Inner Pinion Bearing
5 Inner Pinion Shims
6 Baffle – Pinion Bearing
7 Outer Pinion Shims
8 KIT – Outer Pinion Bearing
9 Slinger – Outer Pinion Bearing
10 Seal – Pinion Oil
12 Washer – Pinion Nut
13 Pinion Nut
16 Carrier Cover Gasket / Sealant
22 Shim – Differential Bearing
24 Bolt – Drive Gear (qty 10)
Differential Case Assembly (standard)
16 Carrier Cover Gasket / Sealant
21 KIT – Differential Bearing
22 Shim – Differential Bearing
23 Case – Differential
24 Bolt – Drive Gear (qty 10)
25 Pinion – Differential
26 Gear – Differential
27 Thrustwasher – Diff. Pinion
28 Thrustwasher – Diff. Gear
29 Shaft – Differential Pinion
30 Lock – Differential Shaft
When replacing Carrier Cover Gasket, replace with same type originally used. RTV tube gasket recommended for
use on flat flange type cover. Paper or cork gasket recommended for use on ribbed flange cover.
Differential Case (standard)
16 Carrier Cover Gasket / Sealant
22 Shim – Differential Bearing
23 Case – Differential
24 Bolt – Drive Gear (qty 10)
30 Lock – Differential Shaft
Differential Parts (standard)
16 Carrier Cover Gasket / Sealant
24 Bolt – Drive Gear (qty 10)
25 Pinion – Differential
26 Gear – Differential
27 Thrustwasher – Diff. Pinion
28 Thrustwasher – Diff. Gear
29 Shaft – Differential Pinion
30 Lock – Differential Shaft
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
ITEM DESCRIPTION
NO.
Kit Components
