X510-8
Axle Axle Kits Shaft & Joint Assy.
Differential
Bill of
Material
Diff.
Type
Ratio
Ring Gear &
Pinion Kit (7) Case Assy.
Kit (8)
Case Kit
Inner Parts
Kit
Right Hand
Shaft Assy.
Left Hand
Shaft Assy.
45
Bill of Material Table
1969 1/2-71 U-100 Bronco
603127-1 Standard 4.10 706503-4X 706004X 706008X 706010X 902754-1 902754-2
603127-2 Powr-Lok 4.10 706503-4X 706002X 706006X 706009X 902754-1 902754-2
603127-3 Standard 4.10 706503-4X 706004X 706008X 706010X 902754-1 902754-2
603127-4 Standard 4.56 706503-5X 706004X 706008X 706010X 902754-1 902754-2
603127-6 Standard 4.56 706503-5X 706004X 706008X 706010X 902754-1 902754-2
603127-7 Standard 3.50 27606X 706003X 706007X 706010X 902754-1 902754-2
603127-8 Powr-Lok 3.50 27606X 706001X 706005X 706009X 902754-1 902754-2
603127-9 Standard 3.50 27606X 706003X 706007X 706010X 902754-1 902754-2
603127-10 Standard 3.50 27606X 706003X 706007X 706010X 902754-1 902754-2
603127-11 Standard 4.10 706503-4X 706004X 706008X 706010X 902754-1 902754-2
603127-12 Powr-Lok 3.50 27606X 706001X 706005X 706009X 902754-1 902754-2
603127-13 Powr-Lok 4.10 706503-4X 706002X 706006X 706009X 902754-1 902754-2
Ford Model 30 Front Axles
Description & Item Number (Refer to Bills of Material
"Exploded View" at the front of this section)
Axle Kits & Parts - Use with All Applications
602905 602963 602990 603127
KIT – Inner Pinion Bearing 4 706015X 706015X 706015X 706015X
Pinion & Bearing Adjusting Shim — 706386X 706386X 706386X 706386X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim — 706360X 706360X 706360X 706360X
(inc. items 5, 7, 12, 13, 16, 22)
KIT – Outer Pinion Bearing 8 706014X 706014X 706014X 706014X
Carrier Cover (inc. 15, 16, 17, 18) — 23350X 23350X 23350X 23350X
Differential Bearing Adj. Shim (16 & 22) — 706087X 706087X 706087X 706087X
KIT – Differential Bearing 21 706016X 706016X 706016X 706016X
Steering Knuckle Assembly N.I. — (3) — (3) — (3) — (3)
(inc. 32, 33, 34, 36, 41, 42)
KIT – Socket Assembly N.I. 33774 33774 34982 34982
(inc. 32, 33, 34, 35, 36, 37, 38)
Stop Screw 39 31026-1 31026-1 31026-1 31026-1
Jam Nut 40 500381-3 500381-3 500381-3 500381-3
KIT – Wheel Bearing Spindle N.I. 27813X 27813X 27813X 27813X
(inc. 47, 48, 48A, 49, 63)
Oil Seal 47 — (3) 34783 34783 34783
Spacer – Wheel Bearing Spindle 48 33996 33996 33996 33986
Needle Bearing Assembly 49 550759 550759 550759 550759
Nut - Brake Mounting 50 30688 30688 30688 30688
Nut & Pin Assembly-Inner Lock 51 21588X 21588X 21588X 21588X
Retaining Lock Nut 52 35461 35461 35461 35461
Wheel Bearing Adjusting Nut 53 31139 31139 31139 31139
Snap Ring 54 31624 31624 31624 31624
Hub Cap 55 31552 31552 31552 31552
Axle Drive Gear 56 31125 31125 31125 31125
Pressure Spring 57 — 35218 35218 35218
Plate-Spring Retaining 58 26124X 26124X 26124X 26124X
KIT – Outer Wheel Bearing 59 706111X 706111X 706111X 706111X
KIT – Inner Wheel Bearing 61 706110X 706110X 706110X 706110X
Oil Seal 62 34611 34611 34611 34613
Hub Lock Assembly N.I. 26133-3X 26133-3X 26133-3X 26133-3X
(3) Contact Vehicle Manufacturer for Service
