X510-9
160
Axle Kits & Small Parts - Use with All Applications
(1) Contact Vehicle Manufacturer
(4) For 1974 use Carrier Cover Kit 706192X
Description & Item Number (Refer to
"Exploded View" at the front of this section)
Bills of Material
602951 603144 603184 603282 603284
603452
Inner Pinion Bearing Kit 4 706015X 706015X 706015X 706015X 706015X
Pinion & Bearing Adjusting Shim — 706360X 706360X 706360X 706360X 706360X
(inc. items 5, 7, 12, 13, 16)
Differential & Pinion Shim — 706386X 706386X 706386X 706386X 706386X
(inc. items 5, 7, 12, 13, 16, 22)
Outer Pinion Bearing 8 706014X 706014X 706014X 706014X 706014X
Carrier Cover (inc. 15, 16, 17, 18) — 706090X 706090X 706090X 706090X 706090X
Differential Bearing Adj. Shim (16, 22) — 706087X 706087X 706087X 706087X 706087X
Differential Bearing 21 706016X 706016X 706016X 706016X 706016X
Seal & Guide Tube 31 36410 36410 36410 36410 —
Steering Knuckle Assembly - RH — 34698 27852X 27854X 28975X 28975X
(inc. items 32, 33, 34, 36, 41)
Steering Knuckle Assembly - LH N.I. 34699 27853X 27855X 28976X 28976X
Socket Assy (32,33,34,35,36,41) — — (4) 30354 30354 706116X 706116X
Stop Screw 39 31026-1 31026-1 31026-1 31026-1 31026-1
Jam Nut 40 500381-3 500381-3 500381-3 500381-3 500381-3
Wheel Spindle Seal & Bearing — — — — — —
(inc. items 47, 48, 48A, 49)
Wheel Bearing Spindle — 27503X 27503X 27503X 27817X 27820X
(inc. items 47, 48, 48A, 49, 50 or 74)
Oil Seal 47 — — — 34783 36544
Spacer - Wheel Bearing Spindle 48 — — — 35986 —
Oil Seal - Block Vee 48A — — — — —
Needle Bearing Assembly 49 18174 18174 18174 550759 —
Nut - Brake Mounting 51 — (1) — (1) 36044 — (1) — (1)
KIT — Inner Wheel Bearing 53 706111X 706111X 706111X — (1) — (1)
KIT — Outer Wheel Bearing 55 706111X 706111X 706111X 706111X 706111X
Gasket-Drive Flange 59 18188 18188 18188 18188 18188
Flange-Axle Drive 60 17153 17153 17153 36436 —
Snap Ring 61 18270 18270 18270 18270 —
Hub Cap 62 17071 17071 17071 32001 — (1)
Lockwasher 64 501209-3 501209-3 501209-3 501209-3 501209-3
Lockwasher-Wheel Bearing 84 17015 17015 17015 17015 17015
Nut-Wheel Bearing 85 17016 17016 17016 17016 17016
Lockwasher-Wheel Bearing Nut 86 17017 17017 17017 17017 17017
Hub Lock Assembly N.I. — (1) — (1) — (1) — —
IHC Model 30 Front Axles
